product description
KEY FEATURES
Engine
Power output3.6 kW
Cylinder displacement72.2 см³
Maximum power speed9300 rpm
Max engine/motor RPM13500 rpm
Idling speed2600 rpm
Torque, max.4 Nm
Torque, max. at rpm6000 rpm
Clutch engagement speed (±120)3500 rpm
Fuel consumption450 g/kWh
Fuel consumption1.6 kg/h
Spark plugChampion RCJ7Y, NGK BPMR7A
Electrode gap0.5 mm
Ignition module air gap0.3 mm
Oil pump typeAutomatic
Oil pump capacity Max18.4 ml/min
Oil pump capacity Min5.9 ml/min
Equipment
Bar length (inch)24″
Chain typeH42
Chain speed at 133% of maximum engine power speed27.5 m/s
Sprocket typeRim 7
Bar mountLarge
Recommended bar length, min-max15-28 in
